Technical Specifications of PIO
| PIO SUGARCANE JUICE MACHINE |
| Machine Net weight |
41 kg |
| Capacity |
120 kg / hour |
| 300 Glasses / Hour |
| Dimensions |
19" x 8" x 15" |
| Electric motor |
0.5 HP,1 phase |
| Full body & contact parts |
Stainless Steel 304 |
| 3 Solid Rollers Material |
Food-grade SS 304 |
| Power Consumption |
Very economical USD 1 for 5000 glasses |
| Load Bearing |
Heavy Duty Cylindrical |
| Reduction Gear box |
Helical (3 stage) |
Features of PIO
- Crushes 120 Kg sugarcane in 1 Hour giving 300 + Glasses of juice each of 200 ml.
- Juice is extracted completely in single crushing. Second crushing not required.
- Very compact, can be moved from one place to another easily.
- Very efficient, sturdy and noiseless.
- Very simple and easy to operate, even a child can easily operate it.
- Runs on single phase, so can be used anywhere. (Where there is electric connection).
- No open parts as in traditional sugarcane crushers. So, contamination from flies and dust is avoided.
- No maintenance required except regular cleaning. Very easy to clean. Just pour 2 glasses of water at sugarcane inlet and machine is cleaned
Accessories with the machine
- Sugarcane cutter
- Scrub for cleaning Sugarcane Sticks
- Brush for Cleaning Sugarcane Rollers
- 2 Strainers (Small & Big) to filter Sugarcane Juice
How to clean the machine
There are 2 types of cleaning this machine.
Semi cleaning:
To clean machine is extremely easy & takes only 10 seconds. Just pour 2 glass of water at sugarcane inlet & machine is cleaned.
Full cleaning:
Open knob (Anticlockwise) below the inlet, open cover, so you can see 3 rollers. Start machine (Reverse) & apply special given brush on rotating rollers & pour some water. Keep hands away. Then stop machine. Close top cover. Thus machine can be fully cleaned.
| COMPARISON CHART |
| PIO SUGARCANE JUICER |
TRADITIONAL SUGARCANE JUICER |
| HIGH GRADE STAINLESS STEEL BODY, SO NO RUSTING |
LOW GRADE C.I. / MS MATERIAL, RUSTING IS POSSIBLE |
| 3 ROLLER EFFICIENT DESIGN |
2 ROLLER IN-EFFICIENT DESIGN |
| INBUILT MOTOR |
MOTOR OUTSIDE |
| CLOSED BODY |
OPEN BODY |
| 100% OPERATIONAL SAFETY |
RISKY FOR OPERATOR |
| MINIMUM SPACE |
MORE SPACE REQUIRED |
| 0.5 HP SINGLE PHASE MOTOR |
2 HP MOTOR NEEDED |
| SUPER HYEGENIC SO INSECTS CAN’T SIT ON MACHINE |
INSECTS ARE FLYING ALL AROUND SO INHYGENIC |
| ZERO MAINTENANCE |
FREQUENT MAINTANANCE |
| USER FRIENDLY |
NOT USER FREINDLY |
| REVERSE MECHANISM |
NOT POSSIBLE |
| 3 ROLLERS BOTH SIDE SUPPORTED |
SOMETIMES HANGING ROLLER ONE SIDE SUPPORTED |
| 65% JUICE EXTRACTION BY WEIGHT OF SUGARCANE BY SINGLE CRUSHING |
UP TO 57% JUICE EXTRACTION BY WEIGHT AFTER 4~5 TIMES CRUSHING |
| ONE TIME CRUSHING, TIME SAVING |
TIME WASTING |
| 41 KG WEIGHT EASY TO CARRY WITH BOTH SIDE HANDLES FOR LIFTING |
125 KG WEIGHT AND HANDLES NOT PROVIDED FOR LIFTING |
| 3 METERS LONG CABLE |
CABLES NOT PROVIDED WITH MOTOR |
| 120 KG CRUSHING CAPACITY PER HOUR = SUGARCANE JUICE 360 + GLASSES |
80 KG CRUSHING CAPACITY PER HOUR = SUGARCANE JUICE 182 GLASSES |
| PIO JUICER CAN BE CARRIED IN 2 WHEELER ALSO |
IT CAN’T BE CARRIED EVEN IN 4 WHEELER CAR |
www.piojuicer.com
